ADS

Ambulance Decontamination System

The ADS provides the most convenient, hands-off solution to decontaminate your vehicle’s passenger compartment quickly, safely, and effectively.

Max Protection

Decontaminate between EVERY patient transport

The AeroClave™ ADS is the first decontamination system directly integrated into your new or existing vehicle. The ADS utilizes an EPA-approved hospital disinfectant to give first responders the ability to decontaminate their vehicles and equipment after every patient transport.

Product details

The ADS provides the most convenient, hands-off solution to decontaminate your vehicle’s patient compartment quickly, safely, and effectively. The AeroClave process provides consistent, reliable delivery of the perfect amount of disinfectant, decontaminating to OSHA and NFPA specifications every time in a matter of minutes.

  • Fast turnaround and hands-free technology allows you to redeploy staff to highest and best use
  • Reduces your staff’s exposure to dangerous pathogens
  • Decontaminate even hard-to-reach surfaces
  • Consistent and reliable delivery of disinfectant, not achievable through manual cleaning methods
  • Environmentally friendly process
  • Low cost of operation and ownership
  • Safe for sensitive equipment
  • Decontaminate between transports for maximum protection
Nozzle Assembly

The nozzle assembly is installed inside the patient compartment to deliver an even blanket of disinfectant to every surface. The mounting bracket pivots to allow for easy positioning on the ceiling, wall or on top of the main module. The standard locations for the nozzle are either over the back doors or on the bulkhead between the patient compartment and the driver’s cab.

The Benefits of ADS

The modular design and small size of the AeroClave ADS allows this unit to be tucked away in a cabinet or on the wall in the patient compartment. It’s always ready to be run at a moments notice while on the road, at the hospital or in the fire station.

  • Automatic, push-button operation using the touchscreen controller
  • Accessible USB port allows for easy download of run data
  • Safety features include motion detector, strobe light and audible warning
  • Flexible mountain options include shelf-mount and wall-mount brackets
  • Easy to fill reservoir holds over a weeks worth of fluid
  • Durable all stainless steel construction
Options & Accessories

AeroClave Portable Applicator

The AeroClave Portable Applicator, or APA, is used for manual hand application of disinfectant on high contact areas to spot treat backboards, stretchers and the exterior of the ambulance.
The APA Module comes with an ADP port to be mounted in an exterior cabinet and the standard 25-foot APA.

Air Compressor Module

Required if on board air is not available. The Air Compressor Module is designed to be mounted anywhere in the ambulance. The kit contains all the tubing and control cable needed to hide the assembly in an exterior cabinet.

ADS Unit Specifications – Main Module
Main Module – p/n ADS-10000
Case dimensions: (H)11.5 in x (W)12.5 in x (D)6.5 in
Exterior: Stainless steel construction
Weight: 15 lbs
Power supply: 12 VDC, 4 amps
Mounting brackets: Both wall-mount and shelf-mount
Remote control range: Maximum 100 ft
Reservoir: 2000 ml with valve
Air requirement: Minimum 1 cfm @ 30 psi
Operating temp: 35°F to 80°F at between 45% to 75% relative humidity
Maximum treatment area: 700 cubic ft
Nozzle Assembly
Case dimensions: (H)2.0 in x (W)5.5 in x (D)4.7 in
Nozzle: Brass or acrylic
Safety components: Motion detector, strobe light and air flow sensor
ADS – Optional Modules
Air Compressor Module – p/n ADS-20000
Unit dimensions: (H)6.75 in x (W)10.5 in x (D)4.5 in
Weight: 12 lbs.
Power supply: 12 VDC, 13 amps
Compressor: Vacuum flow rate: 2.0 cfm | 55.8 l/min
Vacuum continuous: 24.3 in.Hg | -823.7 mbar
Tubing and control wire included
APA Module – p/n ADS-30000
Port bracket dimensions: (H)5.75 in x (W)3.75 in x (D)2.5 in
Tubing and control wire included
Includes standard APA: Spray gun with 25’ hose
Additional Benefits

Lower Cost

Low cost of operation and ownership while providing faster decontamination process requiring less labor.

Fast Process

Improves asset turn-around time to get your vehicles and equipment back in service faster.

Improved Cleanliness

Consistent and reliable delivery of disinfectant, not achievable through manual cleaning methods.

Safety

Safe for your staff, sensitive electronic equipment and the environment.

How the ADS works

Introducing the first decontamination system directly integrated into your new or existing vehicle.

Be Prepared. Decon ALWAYS On-board.

You can mount the ADS inside almost any vehicle. Ask us about the possibilities.
